2.3 Output Terminal
────────────────────────────────────────────────────
WARNING
The minimum load impedance of the analog output terminals is 40 Ω.
Avoid connecting loads with less than 40 Ω, or short-circuiting the
output, as the unit could be damaged or overheat.
CAUTION
Avoid applying external voltage to the analog output terminals, as the unit
could be damaged.
NOTE
2.3 Output Terminal
Waveforms are output from the analog output terminals, with the lowest
terminal being channel 1. BNC cables can be directly connected.
To obtain optimum quality high-frequency waveform output, the load should
be terminated at 50 Ω impedance. In this case, the waveform amplitude is
half of the value set on the 7075.
