Hioki 7075 - Page 4

3.7 Waveform Sweep Settings 27
3.7.1 Selecting the Sweep Settings Screen 28
3.7.2 Selecting the Sweep Waveform 28
3.7.3 Selecting Items to Sweep 29
3.7.4 Sweep Settings (Pulse Waveforms) 29
3.7.5 Non-Selected Sweep Item Settings 30
3.7.6 Selecting the Sweep Editor Screen 30
3.7.7 Selecting the Sweep Items to Edit 31
3.7.8 Setting the Sweep Time 31
3.7.9 Setting the Start Value 32
3.7.10 Setting the End Value 33
3.7.11 Setting the Number of Loops 34
3.7.12 Entering Multiple Lines 34
3.7.13 Inserting a Line 34
3.7.14 Deleting a Line 35
3.7.15 Creating Sweep Data 35
3.7.16 Sweep Data Output 35
3.7.17 Setting the Total Number of Loops 36
3.7.18 Saving Sweep Settings 37
3.7.19 Loading Sweep Settings 37
3.8 Marker Output Function 38
3.8.1 Selecting the Marker Screen 38
3.8.2 Setting the Output Value Marker 39
3.8.3 Setting the Line Marker 41
Chapter 4 Waveform Input Screen 43
4.1 Selecting the Waveform Input Screen 43
4.2 Waveform Input
44
4.2.1 Using the Floppy Disk 44
4.2.2 Using the GP-IB Interface 45
4.3 Input Waveform List Display 46
Chapter 5 FD I/F Screen 47
5.1 Selecting to the FD I/F Screen 47
5.2 Floppy Disk
48
5.2.1 Saving the Settings 48
5.2.2 Reading the Settings 49
5.2.3 Other Operations 50
5.2.4 Formatting the Floppy Disk 51
