Analog Triggers, Pulse Triggers, Waveform Calculation Triggers
Trigger level resolution
The trigger level resolution (minimum setting width) varies with the range.
Input Range Resolution
Voltage 1 mV f.s. 0.001 mV
2 mV f.s. 0.002 mV
5 mV f.s. 0.005 mV
10 mV f.s. 0.01 mV
20 mV f.s. 0.02 mV
50 mV f.s. 0.05 mV
100 mV f.s. 0.1 mV
200 mV f.s. 0.2 mV
1 V f.s. 0.001 V
2 V f.s. 0.002 V
10 V f.s. 0.01 V
20 V f.s. 0.02 V
100 V f.s. 0.1 V
1 to 5 V f.s. 0.01 V
Temperature (for both
thermocouples and resistance
temperature detectors)
100°C f.s. 0.1°C
500°C f.s. 0.5°C
2000°C f.s. 2°C
Humidity 100% RH f.s. 0.1% RH
Resistance 10
Ω
f.s. 0.01
Ω
20
Ω
f.s. 0.02
Ω
100
Ω
f.s. 0.1
Ω
200
Ω
f.s. 0.2
Ω
Integration – 1 c
Rotational speed 5000 r/s 1 r/s
300,000 r/min. 1 r/min.
Strain 1000 μ
ε
f.s. 1 μ
ε
2000 μ
ε
f.s. 2 μ
ε
5000 μ
ε
f.s. 5 μ
ε
10000 μ
ε
f.s. 10 μ
ε
20000 μ
ε
f.s. 20 μ
ε
50000 μ
ε
f.s. 50 μ
ε
100000 μ
ε
f.s. 100 μ
ε
200000 μ
ε
f.s. 200 μ
ε
