Hioki LR8450 User Manual

290
Sending Emails
Email authentication
The instrument supports POP authentication (POP before SMTP) and SMTP authentication for
email.
Congure the settings as necessary.
> >
2
2
3
3
4
4
5
5
6
6
1
1
7
7
1
Press the ENTER key while [E-mail settings...] is selected.
The settings window will open.
2
Select the authentication method to use for email under [Mail authentication] on the [Auth.]
tab.
OFF

Do not authenticate.
POP Use POP authentication (POP before SMTP).
Set the server name, port number, account name, and password.
SMTP Use SMTP encryption.
Set the account name, authentication method, and password.
3
Enter the POP3 server’s name or IP address in the [Server name] eld.
String of up to 45 single-byte characters
4
Enter the POP3 server’s port number in the [Port number] eld.
1 to 110

to 65535
5
Enter the authentication user account in the [Account name] eld.
String of up to 45 single-byte characters
6
Select the method supported by the SMTP server under [Authentication method].
LOGIN

, PLAIN, CRAM-MD5
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki LR8450 Specifications

General

Model	LR8450
Category	Data Loggers
Dimensions	330 mm (12.99 in) W × 221 mm (8.70 in) H × 120 mm (4.72 in) D
Weight	Approx. 2.8 kg (excluding battery)
Operating Temperature	0 to 40 °C (32 to 104 °F), 80% RH or less (no condensation)
Sampling Rate	1 ms to 1 hr
Memory	Internal memory
Interface	USB, Ethernet
Power Supply	AC adapter or battery
Measurement Range	Varies with module
Accuracy	Varies with module
Storage Media	SD card
Memory Capacity	Internal memory
Input Type	Voltage, temperature
Temperature Measurement	Varies with module
Communication Interface	USB, Ethernet
Measurement Channels	Up to 120 channels (with optional input modules)
