Conguring Input Channels
Measuring humidity
This section describes how to congure settings on the individual settings screen when measuring
humidity with the optional Humidity Sensor.
You can use [Input] on the settings list screen to congure the settings. (See p. 67.)
Applicable modules: U8550, U8551, U8552, LR8531
Applicable sensor: Z2000 Humidity Sensor
> >
3
3
1
1
2
2
1
Select the module (Unit) and channel to congure and select the check box.
Measurement will not be performed for channels whose check boxes are not selected.
2
Select the waveform display color.
× (OFF), 24 colors
Select [×] if you wish to measure the channel but not to display its waveform or numerical values on the
screen.
3
Set the input type to [Humidity].
There is no range setting (the setting cannot be changed from the 100% RH range).
The measurable range will appear.
