Numerical and Waveform
Calculations
The instrument can perform numerical and waveform
calculations.
You can use numerical calculations to calculate values such
as the maximum value and minimum value for measured
waveforms.
Waveform calculation functionality allows you to perform
calculations on waveforms, for example by adding or
multiplying waveforms from di󰀨erent channels.
6.1 Performing Numerical Calculations....................................p. 192
Conguring numerical calculations.........................................................p. 194
Real-time numerical calculations (automatic calculations) .....................p. 197
Numerical calculations after measurement (manual calculations) .........p. 198
Partial numerical calculations .................................................................p. 199
Numerical calculation formulas .............................................................. p. 200
6.2 Performing Waveform Calculations ....................................p. 202
Conguring calculations on the calculation list screen ...........................p. 207
Copying calculation formulas ................................................................. p. 208
Conguring waveform calculation settings at once ................................ p. 209
