Activating a Trigger at a Set Interval
2.7 Activating a Trigger at a Set Interval
Interval triggers
This section describes how to activate a trigger at a set interval.
When you set the interval trigger to [OR] or [AND], the repeat recording setting will be set to [ON]
automatically.
Interval triggers are disabled when using the Logger Utility.
> >
1
2
1
Under [Interval trigger], select the interval trigger conditions.
If you wish to give priority to the interval trigger, use the [OR] setting. (p. 131)
If you wish to give priority to other triggers, use the [AND] setting. (p. 131)
OFF
Does not use the interval trigger.
OR Uses the interval trigger based on OR logic.
AND Uses the interval trigger based on AND logic.
2
Set the interval for the interval trigger.
DD, HH:MM:SS
The trigger will simultaneously activate when measurement starts. Subsequently, the trigger will activate at
every interval trigger interval.
