Hioki LR8450 User Manual

217
Controlling the System
Synchronizing the time
This section describes how to synchronize the instrument’s time with an NTP server.
The LAN settings must be congured in advance.
See “9.3 Conguring and Establishing a LAN Connection” (p. 239).
> >
1
1
2
2
3
3
4
4
6
6
7
7
5
5
1
Press the ENTER key while [NTP settings...] is selected.
The settings window will open.
2
Set the [NTP client function] to [ON].
3
Under [Sync timing], select when to connect to the NTP server and set the time.
OFF

Does not set the time.
Every hour Sets the time once an hour.
Every day Sets the time once a day.
4
Under [Sync before start], select whether to connect to the NTP server and set the time
before starting measurement.
OFF

, ON
5
Under [Server address], set the address of the NTP server.
6
Press the ENTER key while [Sync now] is selected.
Once the settings have been applied, the instrument will connect to the specied NTP server and
set the time.
7
Press the ENTER key while [Apply] is selected.
The settings will be applied.
Press the ENTER key while [Cancel] is selected to close the window without changing any
settings.
Conguring System Settings
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki LR8450 Specifications

General

Model	LR8450
Category	Data Loggers
Dimensions	330 mm (12.99 in) W × 221 mm (8.70 in) H × 120 mm (4.72 in) D
Weight	Approx. 2.8 kg (excluding battery)
Operating Temperature	0 to 40 °C (32 to 104 °F), 80% RH or less (no condensation)
Sampling Rate	1 ms to 1 hr
Memory	Internal memory
Interface	USB, Ethernet
Power Supply	AC adapter or battery
Measurement Range	Varies with module
Accuracy	Varies with module
Storage Media	SD card
Memory Capacity	Internal memory
Input Type	Voltage, temperature
Temperature Measurement	Varies with module
Communication Interface	USB, Ethernet
Measurement Channels	Up to 120 channels (with optional input modules)
