This chapter describes how to assign event marks to
waveforms during measurement.
(Up to 1000 marks can be assigned.)
You can also search for event marks and jump to their display
positions.
Event marks can be assigned by means of the following four
methods:
• Pressing the START key during measurement
• Press the ENTER key while [Mark] is selected.
• Input the signal in the I/O 1 to 3 terminals during
measurement.
• Previously set the event mark setting so that event marks
can be assigned when alarms occur
5.1 Assigning Event Marks during Measurement .................... p. 186
5.2 Assigning Event Marks with an External Signal ................ p. 187
5.3 Assigning Event Marks When Alarms Occur .....................p. 188
5.4 Searching for Event Marks ..................................................p. 189
5.5 Reviewing Events in CSV Data............................................p. 190
