Hioki LR8450 - Configuring CAN Settings

180
Conguring Alarms
Conguring CAN settings
This section describes how to select CAN channels as alarm conditions. Up to 100 channels can
be specied.
> >
List screen
1
1
3
3
2
2
4
4
5
5
6
6
7
7
1
1
1 to 100 100 alarm conditions
2
2
Un-m
Rn-m
(n = 1, 2, . . ), (m = 1, 2, . . .)
Displays the CAN Unit numbers and channel numbers that are currently
congured.
Pressing the ENTER key will open the “Individual settings” window.
3
3
Edit Indicates that the CAN channel is not selected.
Pressing the ENTER key will open the “Individual settings” window.
See “CAN individual settings window” (p. 181).
4
4
Comment Displays the CAN channel’s comment.
5
5
Ch type Displays the CAN channel’s type.
6
6
ID Displays the CAN channel’s ID.
7
7
ALM1 to ALM8 Displays the alarm type.
