181
Conguring Alarms
Unit Measure Channel Trigger Alarm Calculation System
CAN individual settings window
1
1
2
2
3
3
1
Under [Alarm No], select the trigger number from the 100 alarm conditions.
2
Under [CAN Channel], set the CAN unit and channel to specify as the alarm condition.
The channel type, ID, and comment for the specied CAN channel will be displayed.
3
The channel type, ID, and comment for the specied CAN channel will be displayed.
OFF Disables the alarm function.
Level See “Level” (p. 176).
Window See “Window” (p. 176).
Slope See ”Slope” (p. 176).
Alarm (Alarm Output)
