6.2 Performing Waveform Calculations
This section describes how to perform basic arithmetic operations between channels and how to
calculate values such as a moving average. (Up to 30 calculations can be performed.)
The following types of calculations are available: basic arithmetic operations, integration, simple
average, moving average, and integral.
Calculations are performed in real time while measurement continues, and post-calculation
waveforms are displayed.
Waveform calculations cannot be performed after measurement.
Waveform calculation results are displayed in the calculation channels ([W1] to [W30]).
> >
5
5
2
2
1
1
3
3
4
4
1
Select the item to display.
Formula

, Display, Comment, Numerical calc
Calculation list screen: [Display] Calculation list screen: [Comment]
Calculation list screen: [Numerical calc]
