Text Format
11.8 Text Format
Files saved in the text format consist of header and data sections.
The header includes the following information:
(1) Filename and version number
(2) Title comment
(3) Trigger time
(4) Channel number for each column*
1
(5) Measurement*
2
(6) Range
(7) Module identier
(8) Comments
(9) Scaling setting
(10) Scaling conversion ratio
(11) Scaling o󰀨set
(12) Channel number*
1
and module for each row
(13) Data*
3
"File name","AUTO0001.CSV","V 1.00" ....................................................................................................(1)
"Title comment"..........................................................................................................................................(2)
"Trigger Time","19-12-26 10:15:32" ........................................................................................................... (3)
"CH","U1-1","ALM1","ALM2"," ALM-SOURCE-1-U1"," ALM-SOURCE-2-U1","W1", ................................. (4)
"Mode","Voltage","Alarm","Alarm","Alarm Source","Alarm Source","Calculation", ....................................(5)
"Range","1V","","","","","", ...........................................................................................................................(6)
"UnitID","","","","","","","","" ..........................................................................................................................(7)
"Comment","","","","","","","","", ...................................................................................................................(8)
"Scaling","OFF", ........................................................................................................................................(9)
"Ratio","1.00000E+00",............................................................................................................................(10)
"O󰀨set","0.00000E+00", .......................................................................................................................... (11)
"Time","U1-1[V]","ALM1","ALM2"," ALM-SOURCE-1-U1","ALM-SOURCE-2-U1","W1[V]",
"CAN-INVL-FLAG","Event", ..................................................................................................................... (12)
0.000000000E+00, -3.3250000000E-02,0,0, "","", -6.6500000000E-02,00H,0, ......................................(13)
1.000000000E-01, 2.8500000000E-02,1,0, "80000000H","", 5.7000000000E-02,00H,0,
2.000000000E-01, 9.6000000000E-03,0,0, "","", 1.9200000000E-02,00H,0,
3.000000000E-01, -2.5600000000E-02,0,0, "","", -5.1200000000E-02,00H,0,
4.000000000E-01, 4.5600000000E-02,1,1, "80000000H ","80000000H", 9.1200000000E-02,00H,0,
*1: Channel numbers are outputted on a data type by data type basis as follows:
Analog plug-in (Uxa-xx), Analog wireless (Rxb-xx), pulse (Py), logic (Ly), alarm (ALMy), alarm
source (ALM-SOURCE y-z), and waveform calculation (Wxx).
(xa: 1 to 4, xb: 1 to 7, xx: 1 to 30, y: 1 to 8, z: U1 to U4 / R1 to R7 / P/L/W/OTHER)
If statistical values have been selected as the saved data, columns for the average value (ave),
maximum value (max), and minimum value (min) will be added for each parameter.
However, no average value will be provided for data that triggered an alarm.
