Sending Data Using the FTP Client
9.7 Sending Data Using the FTP Client
This section describes how to send les saved automatically on instrument media (SD Memory
Card and USB Drive) to an FTP server on a computer.
To do so, specify the IP address of a computer on which an FTP server is running.
You will need to register the instrument’s username and password with the FTP server. For more
information, see the Windows
®
FTP server’s help le.
You can use the Windows
®
FTP server or another server.
Apart from the Windows
®
FTP server, you can use shareware such as FileZilla Server.
• Set [Measure] > [Auto save] > [Waveform] > [Format] to any setting other than “OFF.”
• To send data at a regular interval, set the segmentation method to [Enable] or [Timed] under the
auto saving [File splitting] setting.
• To continue sending data even if the SD Memory Card runs out of space, set the processing
method to use when the media runs out of space to [ON] under [Deleting].
See “Auto save (real-time save)” (p. 142).
1
Congure the LAN settings and establish a LAN connection. (p. 239)
2
Congure the FTP server on the computer. (p. 266)
3
Enable automatic sending of les via FTP on the instrument. (p. 280)
4
Congure auto saving on the instrument. (p. 142)
5
Start measurement on the instrument.
When data is automatically saved by the instrument, the le will be automatically sent to the
computer’s FTP server.
6
Check the communications. (p. 283)
Communicating with a Computer (PC)
HIOKI LR8450A964-03
