125
Logic Triggers (Patterns)
3
Select the P1 to P8 trigger pattern.
0 Activates the trigger when the signal is [0] (low).
1 Activates the trigger when the signal is [1] (high).
X Excludes from the trigger. The signal will be ignored.
Trigger Function
