205
Performing Waveform Calculations
9
(When [Type] is set to [Aggregation], [Simple average], or [Integration])
Under [Reset start time], select the reset operation to perform when measurement starts.
9
9
10
10
11
11
OFF

Does not reset calculation results.
Trigger position Resets calculation results when a trigger activates.
10
(When [Type] is set to [Aggregation], [Simple average], or [Integration])
Under [Reset time], select when to perform reset operation.
Disable

Does not reset calculation results.
Enable Resets calculation results at the set time intervals.
Timed Resets calculation results at the set intervals starting at the specied time.
11
(When [Reset time] is set to [Enable])
Set the [Reset interval].
(When [Reset time] is set to [Timed])
Set the [Reference time] and [Reset interval].
Numerical and Waveform Calculations
HIOKI LR8450A964-03
