Hioki LR8450 - Page 273

268
Sending Data Using the FTP Client
4
Right-click the item displayed under
[Connections] on the left pane and
click [Add FTP Site...] on the shortcut
menu.
Communications may be blocked
depending on how any security software
(for example, a rewall) has been
congured.
5
Enter the [FTP site name].
Example: ftp
In [Physical path] under [Content
Directory], specify the location where
data from FTP clients should be saved.
Example: C:\inetpub\ftproot
Click [Next].
6
Set [Binding] and [SSL] as follows:
[IP Address] [All Unassigned]
[Port] [21]
[Start FTP site
automatically]
Select.
[SSL] [No_SSL]
Click [Next].
