296
Dimensions
(excluding protrusions)
(excluding protrusions)
(excluding protruding parts)
Weight Approx. 1.1 kg (38.8 oz.)
Standards Safety EN 61010
EMC EN 61326 Class A
Vibration resistance
Class 1: Passenger vehicles; conditions: Class A equivalent
(4 h along X-axis and 2 h along Y- and Z-axes at a vibration acceleration of 45 m/s
2
-2. Display
Display
Display resolution
(with waveform
display selected)
Max. 20 divisions (horizontal axis) × 10 divisions (vertical axis)
Display language
Backlight service life Approx. 100,000 h (reference value at 23°C)
Backlight saver
Backlight brightness 5 levels (user-selectable)
Waveform background
color
Dark/light (user-selectable)
-3. Power supply
Power supply AC adapter
AC Adapter rated supply voltage
AC Adapter rated power supply frequency
50 Hz/60 Hz
Battery The instrument accommodates two batteries.
Z1007 Battery Pack
(When used with AC Adapter, AC Adapter has priority.)
Li-ion, 7.2
V, 2170 mAh
External power supply 10
V to 30 V DC
Power consumption Normal power
consumption
Using Z1014 AC Adapter or 12 V DC external power supply,
without Battery Pack
With LCD at maximum brightness: 8.5
VA (instrument only)
Maximum rated power When using the Z1014 AC Adapter
When using a 30
V DC external power supply
28
VA (while charging battery with LCD at maximum
brightness)
When using the Z1007 Battery Pack
20 VA (with LCD at maximum brightness)
