Reference junction
compensation
Internal/external (user-selectable) (during thermocouple measurement)
Thermocouple wire
break detection
The system will check for wire breaks at the date refresh intervals during thermocouple
measurement.
Setting not available when the data refresh interval is set to 10 ms.
Setting not available when the data refresh interval is set to 20 ms and 16 or more
channels are being used.
Data refresh interval 10 ms*
1
, 20 ms*
2
, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s
*1: Setting available when thermocouple wire break detection is disabled and the number
of channels in use ranges from 1 to 15.
*2: Setting available when thermocouple wire break detection is disabled and the
number of channels in use ranges from 16 to 30. Alternatively, setting available when
thermocouple wire break detection is enabled and the number of channels in use
ranges from 1 to 15.
Digital lters
according to the number of channels in use, data refresh interval, Wire break detection
(1) When the number of channels in use is 15 or less
–: Setting not available
Power
supply
frequency
lter setting
Wire
break
detection
setting
Data refresh interval
10 ms 20 ms 50 ms 100 ms 200 ms 500 ms 1 s 2 s 5 s 10 s
60 Hz 20.8 k 2.37 k 60 60 60 60 60
On – 20.8 k 2.37 k 60 60 60 60
50 Hz 20.8 k 2.37 k 50 50 50 50 50
On – 20.8 k 2.37 k 50 50 50 50
Unit: Hz
(2) When the number of channels in use is 16 to 30
–: Setting not available
Power
supply
frequency
lter setting
Wire
break
detection
setting
Data refresh interval
10 ms 20 ms 50 ms 100 ms 200 ms 500 ms 1 s 2 s 5 s 10 s
60 Hz – 20.8 k 2.37 k 60 60 60 60
On – – 20.8 k 2.37 k 60 60 60
50 Hz – 20.8 k 2.37 k 50 50 50 50
On – – 20.8 k 2.37 k 50 50 50
Unit: Hz
