Measurement
target
Type Range
Maximum
resolution
Measurable range
Measurement
accuracy
Thermocouple
(Not including
accuracy of
reference
junction
compensation)
B 2000°C f.s. 0.1°C Greater than or equal to
400°C and less than 600°C
±5.4°C
Greater than or equal to
600°C and less than 1000°C
±3.7°C
Greater than or equal to
1000°C and less than or
equal to 1800°C
±2.4°C
C 100°C f.s. 0.01°C 0°C to 100°C ±1.7°C
500°C f.s. 0.05°C 0°C to 500°C ±1.7°C
2000°C f.s. 0.1°C 0°C to 2000°C ±1.7°C
Humidity – As per
measurement
accuracy of the
Z2000 Humidity
Sensor
5030200
0
5
60
80
95
100
±8% RH
±6% RH
±5% RH
±10% RH
±8% RH
±6% RH
±10% RH
±8% RH
±6% RH
Temperature (°C)
Humidity accuracy table
: Out of accuracy guarantee range
Each boundary line is included in the better measurement accuracy area.
Resistance
temperature
detector
Pt100 100°C f.s. 0.01°C ±0.5°C
500°C f.s. 0.05°C ±0.7°C
2000°C f.s. 0.1°C
JPt100 100°C f.s. 0.01°C ±0.5°C
500°C f.s. 0.05°C ±0.7°C
2000°C f.s. 0.1°C
Pt1000 100°C f.s. 0.01°C ±0.5°C
500°C f.s. 0.05°C ±0.7°C
2000°C f.s. 0.1°C
Resistance – 10
f.s. 0.5 m
0
to 10
±10 m
20
f.s. 1 m
0
to 20
±20 m
100
f.s. 5 m
0
to 100
±100 m
200
f.s. 10 m
0
to 200
±200 m
Reference junction
compensation
±0.5°C (with input terminal temperature balancing)
Reference junction compensation: Add thermocouple measurement accuracy when set to
internal.
Temperature
characteristics
information about the humidity accuracy, see the humidity accuracy table).
