364
Options Z3230 Wireless LAN Adapter
Z1007 Battery Pack
C1012 Carrying Case
2. Input, output, and measurement specications
-1. Basic specications
Number of input
channels
5 channels (Set voltage or strain for each channel.)
Input terminals
Set DIP switches according to the measurement target.
Measurement target Voltage
Strain Strain gage-type converter
Strain gage
1-gage method (2-wire setup), 1-gage method (3-wire setup),
2-gage method (adjacent sides), 4-gage method
Adaptive gage
resistance
1-gage method, 2-gage method: 120
(external bridge box required for 350
)
4-gage method: 120
to 1 k
Gage factor
Bridge voltage 2 V DC ±0.05 V
Balance adjustment Input type Method
Range Voltage: ±20 mV or less (1 mV f.s. to 20 mV f.s. ranges),
±200 mV or less (50 mV f.s. to 200 mV f.s. ranges)
Strain: ±20,000 µ
ε
ε
ε
f.s. ranges),
ε
ε
ε
f.s. ranges)
Input type
A/D resolution 16 bits
Maximum input
voltage
±0.5 V DC
Maximum channel-to-
channel voltage
Non-isolated (all channels share common GND)
Maximum rated
terminal-to-ground
voltage
30 V rms AC or 60 V DC (between each analog input channel and the enclosure)
Anticipated transient overvoltage: 330 V
Input resistance 2 M
Data refresh interval 1 ms, 2 ms, 5 ms, 10 ms, 20 ms, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s
Low-pass lter
Auto, 120, 60, 30, 15, 8, 4 (Hz)
following table based on the set data refresh interval:
Data refresh interval
1 ms 2 ms 5 ms 10 ms 20 ms 50 ms 100 ms 200 ms 500 ms 1 s 2 s 5 s 10 s
120 Hz 60 Hz 30 Hz 15 Hz 8 Hz 4 Hz 4 Hz 4 Hz 4 Hz 4 Hz 4 Hz 4 Hz 4 Hz
Attenuation
characteristics
