Hioki LR8450 - Page 51

46
Conguring CAN Settings
6
(If operating in [Measured value output mode])
Select whether to output measured values under [Measured value output].
Settings controlling measured value output are congured with the CAN Editor. On the LR8450,
you can select whether to output measured values overall.
OFF Disables CAN Unit measured value output.
ON

Enables CAN Unit measured value output.
7
Send the CAN Unit settings from the LR8450 to the CAN Unit with [Apply].
Even if you don’t send the settings, they will be sent when measurement starts.
8
Press the ENTER key while [ID search] is selected.
The instrument will search IDs received by the target CAN Unit and display a dialog box.
