61
Using the Scaling Function
Scaling settings during integration measurement
You can use the scaling function to convert the integrated pulse count to the measurement target’s
physical properties (watt hours, volt-amperes, etc.) and then display or record the result.
The pulse output device will have predetermined physical quantity that corresponds to 1 pulse or
a number of pulses that corresponds to a value of one in the basic units (for example, 1 kWh, 1 L,
1 m
3
).
> >
2
2
3
3
1
1
1
Select the scaling display method.
OFF

Does not use the scaling function.
Decimal Displays converted values as decimals.
Exponent Displays converted values as exponents.
2
Enter the post-conversion unit (up to 7 single-byte characters).
See “Text entry method” (p. 10).
Settings and Operation
HIOKI LR8450A964-03
