7 - 37
7.5.3 Mechanism Check
Function : The reaction disk, sampling system, reagent dispensing system, cell rinse
system, stirring system and ISE system are made to operate the same as in
the operation status.
Required time: Reset 20 sec + mechanism check 18 sec/cycle × X times
Processing
No.
Details of Processing Reference Document
1)
Start from MAINTENANCE screen Screen specifications
2)
Refer to the following page.
3)
At mechanism check, operation is checked and alarm is
displayed on the instrument monitor screen if operation
is abnormal.
Screen specifications
Alarm code table
4)
The above alarm is stored in FD. FD specifications
Remarks: Operation is repeated until the End key is input.
START
Input of "Execute"
Input of "Stop"
MAINTENANCE
screen
Mechanism check
required?
Mechanism check
Alarm indication
FD (alarm logging)
Judgement
by operator
Abnormal
Normal
No
Yes
Operation check
END
1)
2)
3)
4)
To Next Page
