(5) Screen Displayed in Case of Failure in Screen Information Transfer
Screen data is destroyed.
Screen information transfer has failed. (Execute installation again.)
After initialization of the LCD module memory (refer to 12.12.5), carry out "Procedure for
Installation of Screen Information (installation)" again.
12.11.5 Procedure for Initial Setting of LCD Module
Explained below is initialization of the LCD module memory.
(1) Display of System Menu
Power on the 902 main unit.
When there is no image data, "System Menu" is displayed.
When the operation mode (RUN lamp lit) is set, press the touch switch to display "System
Menu".
(2) Initial Screen
Display immediately after turning on power when image data is not registered (space
display)
Display immediately after turning on power when image data is destroyed
[System Menu]
[Menu End]
[Transfer Mode]
[Maintenance Mode]
Screen data is destroyed.
