Hitachi 902 - Detector List

8 - 2
8.2 Detector List
No. Class Application Type Detection Part No.
1 PCP Home position of reaction disk P1144-03 Dark 713-4142
2 PCP For reaction disk count (37365204) Bright 713-4143
3 PCP For reaction disk ADC (37365204) Bright 713-4143
4 PCP Home position of S disk GP1A34 Dark J339165
5 PCP For outer track of S disk ↑ Bright ↑
6 PCP For inner track of S disk ↑ Bright ↑
7 PCP Home position of R disk ↑ Dark ↑
8 PCP For R disk count ↑ Bright ↑
9 PCP Home position of S probe rotation P1144 Dark 707-0426
10 PCP Upper dead point of S probe GP1A34 Dark J339165
11 Conduction Liquid level sensor for S probe   707-5041
12 PCP Abnormal descent of S probe EE-SX405 Dark ↑
13 PCP Home position of R probe rotation P1144 Dark 707-0426
14 PCP Upper dead point of R probe GP1A34 Dark J339165
15 Conduction Liquid level sensor for R probe   707-5041
16 PCP Abnormal descent of R probe EE-SX405 Dark ↑
17 PCP Upper dead point of rinse mechanism GP1A34 Dark J339165
18 PCP Upper dead point of stirring mechanism ↑ Dark ↑
19 PCP Home position of stirring mechanism
rotation
↑ Bright ↑
20 PCP Stop position of stirring mechanism
rotation
↑ Bright ↑
21 PCP Upper dead point of S syringe GP1A04 Dark 713-0315
22 PCP Upper dead point of R s yringe GP1A04 Dark 713-0315
23 PCP Upper dead point of ISE syringe GP1A04 Dark 713-0315
24 PCP Upper dead point of ISE arm GP1A34 Dark J339165
25 Float SW Water level in water tank   713-0319
26 Vacuum SW Negative pressure in vacuum chamber   713-0312
27 Conduction Waste solution level in vacuum chamber   713-0318
28 Conduction Water level in incubation bath   714-4043
29 Conduction Waste solution full   714-0391
30 Pt feeler For control of temperature in incubation
bath
  717-0242
