12.11.2 Procedure for Installation of Product Program
(1) Load the installation FD (no. 1) into drive 1 (left FDD), and turn on the main switch of the
instrument.
(2) The screen given below then appears.
(If the screen given below does not appear (if the space screen is displayed), it is
necessary to execute installation of screen information (initialization) with reference to
12.12.4.
(If the message "Screen data is destroyed." is displayed, it is necessary to initialize the
image memory. Execute initialization of the LCD module memory.)
Wait for 7 min.
XXX
The program is loaded and the next screen is displayed.
(3) Display of Installation Menu Screen
[Installation Menu]
[1. System File Only]
[2. Screen Information (+ System File)]
[3. End]
Waiting for Selection of Installation Function
[1. System File Only] : Updating of product program alone
[2. Screen Information (+ System File)]: Updating of screen information and product
program
[3. End] : End (suspension of installation)
Press the [2. Screen Information (+ System File)] key.
The next screen is displayed.
(4) Installation Instruction Screen
1. Touch both ends of "screen" to dis-
play System Menu screen.
2. Press "Transfer Mode" key.
Simultaneously press 2 touch switches at the corners of the screen.
The system menu is displayed. (The next screen appears.)
