12.11.4 Procedure for Installation of Screen Information (initialization)
(1) Load the installation FD (no. 1) into drive 1 (left FDD), and turn on the main switch of the
instrument.
(2) The space screen is presented.
When the program is loaded, "buzzer" sounds.
Simultaneously press 2 touch switches at the corners of the screen. The system menu is
displayed. (The next screen is displayed.)
(3) System Menu Screen
[System Menu]
[Menu End]
[Transfer Mode]
[Maintenance Mode]
Press [Transfer Mode] key to enter transfer mode.
The next screen is displayed.
(4) Screen Information Transfer Screen
[Transfer Mode]
Tool –> PT
Screen data
XX kbyte
[Stop]
The indication of memory capacity changes during transfer.
When the memory indication (XX kbyte) is cleared, press [Stop] key.
After that, perform step no. 7 and subsequent of the procedure for installation of the
product program.
In case of a failure in screen information transfer, the next screen is displayed.
