8. MOTORS, DETECTORS AND FUSES
8.1 Motor List
No. Mechanism Name Motor Type Part No.
Controller
(EMOT200)
Output Buffer (DRV)
1 Reaction disk rotation PH265M-31-A5 713-0266 GPCONT-6
2 Sample disk rotation KP56KM1-014 707-0226 GPCONT-1
3 Reagent disk rotation ↑ 707-0226 GPCONT-2
4 Rinse up/down C6360-9212 707-0937 GPCONT-2
5 Sample arm rotation PX245M-02A 707-0298 GPCONT-3 SLA7021M
6 Sample arm up/down KP56KM1-014 707-0226 GPCONT-3 (constant-current drive)
7 Reagent arm rotation PX245M-02A 707-0298 GPCONT-4
8 Reagent arm up/down KP56KM1-014 707-0226 GPCONT-4
9 Stirrer arm rotation PX243M-03A 707-0300 GPCONT-5
10 Stirrer arm up/down C6470-9212 707-0936 GPCONT-5
11 ISE sipper arm up/down PX244M-02A 713-0326 GPCONT-6
12 Sample syringe SM55-4802 713-0316 GPCONT-7 MP4501
13 Reagent syringe ↑ 713-0316 GPCONT-7 (constant-voltage
drive)
14 ISE syringe ↑ 713-0316 GPCONT-8
15 Stirring rod rotation LN12-M421N1B 707-0285 GMCONT HD75452P
