Hitachi 902 - Data Composition; SD Value Information (8 Characters); Transfer of ISE Calibration Data (from Analyzer to Host)

16 - 36
7) SD value information (8 characters)
SD decimal point position
SD value (right-justified and preceded by space)
"Y": SD value present
"N": SD value absent (Spaces remain blank for information on
SD value and decimal point position.)
8) Data composition
Table 16-20
Data Item Unit Form Decimal Point Position
Absorbance data 10
-4
ABS 6-digit integer with sign No decimal point
Initial absorbance
data
10
-4
ABS 6-digit integer with sign No decimal point
SD value No 6 digits with decimal
point (positive)
Decimal point position of
SD limit on chemistry
parameter screen
9) Transfer unit
Transfer in units of channel
(d) Transfer of ISE calibration data (from analyzer to host)
Composition of text (B: Byte count)
1B 1B 2B 1B 1B 72B
Type A STX : H ISE type Na data alarm Na calibration data
1B 72B 1B 1B
K data alarm K calibration data ETX BCC (Unused) (153 bytes)
Type B STX : H ISE type Na data alarm Na calibration data
1B 72B
K
data alarm
K
calibration
data
Cl
data alarm
Cl
calibration
data
ETX BCC (226 bytes)
1) Frame character (1 character)
':' is transferred.
2) Function character (2 characters)
'H_' is transferred.
10
5
10
0
Transfer sequence
