3 - 1
3. FLOW PATH DIAGRAMS
3.1 List of Solenoid Valves
SV No.
2-way/
3-way
Type
Open/Close
When
Energized
Voltage Maker Application Part No.
SV 1 2-way A2-5617 Open 24 V DC CKD Water supply intake 713-0321
SV 2 2-way HB-11-X0185 Open 24 V DC CKD Sample syringe 713-1059
SV 3 2-way HB-11-X0185 Open 24 V DC CKD Reagent syringe 713-1059
SV 4 2-way HB-11-X0193 Open 24 V DC CKD Incubation bath water intake 713-1379
SV 5 2-way HB-11-X0193 Open 24 V DC CKD
Stirring and washing water
supply
713-1379
SV 6 2-way HB-11-X0193 Open 24 V DC CKD
Reagent probe outside
washing water supply
713-1379
SV 8 2-way HB-11-X0193 Open 24 V DC CKD
Sample probe outside
washing water supply
713-1379
SV 9 2-way HB-11-X0193 Open 24 V DC CKD
Rinsing and nozzle tip
washing water supply
713-1379
SV 10 2-way HB-11-X0193 Open 24 V DC CKD
Rinsing and cell blank water
supply
713-1379
SV 11 3-way A2-5619 – 24 V DC CKD
Rinsing and cell washing
water supply
707-0290
SV 12 2-way NTV-2-HN Open 24 V DC Takasago
Waste solution discharge
(low concentration)
713-0331
SV 13 2-way NTV-2-HN Open 24 V DC Takasago
Waste solution discharge
(high concentration)
713-0331
SV 14 3-way NRV – 24 V DC Takasago Vacuum tank (evacuation) 713-0332
SV 15 2-way A2-5618 Open 24 V DC CKD
Incubation bath water
discharge
713-0320
SV 16 2-way MTV-21-SM6M Open 24 V DC Takasago ISE syringe 713-0317
SV 17 2-way MTV-21-SM6M Open 24 V DC Takasago ISE sample discharge 713-0324
SV 18 2-way MTV-21-SM6M Open 24 V DC Takasago ISE and REF aspiration 713-0325
SPV 1 Pinch
valve
SD10BA-2A-00T Open 24 V DC Advance ISE aspiration 707-0327
