10 - 3

10.2 ECPU237 Board

(1) Parts Mounting Diagram

Given below is the parts mounting diagram of the ECPU237 board.

P ABORT SW

LED

indication

RESET

SW

RSCN

(for debugging)

MBSICN

(RS232C × 4ch)

AUICN

(for Ethernet)

SW1

(boot I/O setting)

Connector for battery

Self-diagnosis indicator LED
