Hitachi 902 - Arrangement of Circuit Boards; MVSB100 Board (271-3789)

10 - 17
10.5 MVSB100 Board
(1) Explanation of Circuit Board
This circuit board is a mother board which is compatible with the VME bus and has six
slots.
(2) Arrangement of Circuit Boards
Slot No. Circuit Board
1 ECPU 237
2 Unused
3 Unused
4 EMIO100
5 EMOT200
6 DI
NOTE: Slot no. 1 is located at the left as
viewed from the front.
