88
Configuring Presets, Tours, Privacy Zones, Sectors, and Alarms
Configuring Sectors
Sectors are labeled areas that are monitored by the dome. For example, you can
set the dome to display the label "Exit Door" on the screen whenever the dome
is positioned to monitor an exit door.
Programming a Sector
You can program up to 16 sectors. If you program overlapping sectors, the
sector names will alternate on the screen at 1.5 second intervals.
To program a sector:
1. Using the PTZ controls, position the dome (pan and tilt) and lens (zoom,
focus, and iris) so that the area you want to label appears on the screen.
2. In the PTZ Dome Setup tab, in the PTZ Settings panel, under
Sector/Privacy Zone Details, click Program.
3. Type a number for the sector and then press ENTER.
4. Press S to save the current sector coordinates.
The message
Go to lower left corner and press Enter when done
appears.
5. Position the dome so that the lower left corner of the sector is centered on
the screen, and then press ENTER.
The message
Go to upper right corner and press Enter when done
appears.
6. Position the dome so that the upper right corner of the sector is centered on
the screen, and then press ENTER.
7. Program another sector or press ESC to exit.
