Honeywell equIP Series Installation And Configuration Guide

114
ACUIX IP Specifications
Scan Assembly Specifications
Operating
Temperature
• 10°C to 55°C
(14°F to 131°F)
• 10°C to 55°C
(14°F to 131°F)
• 40°C to 55°C
(• 40°F to 131°F)
• 40°C to 55°C
(• 40°F to 131°F)
Operating Humidity 0 to 95%,
non-condensing
0 to 95%,
non-condensing
0 to 95%,
non-condensing
0 to 95%,
non-condensing
Storage
Temperature
• 40°C to 60°C
(• 40°F to 140°F)
• 40°C to 60°C
(• 40°F to 140°F)
• 40°C to 60°C
(• 40°F to 140°F)
• 40°C to 60°C
(• 40°F to 140°F)
Table A-4 Scan Assembly Model Numbers with Camera Type
Board Type Scan Assembly (NTSC/PAL) Camera Type
NetCore HDCAN0000
HDCJN0000
HDCFN0000
HDCGN0000
HDCAP0000
HDCJP0000
HDCFP0000
HDCGP0000
18× Color (HDXA)
18× WDR/TDN (HDXJ)
26× WDR/TDN (HDXF)
35× WDR/FNR (HDXG)
NetCore 2 HDCAN0000V2
HDCJN0000V2
HDCFN0000V2
HDCGN0000V2
HDCAP0000V2
HDCJP0000V2
HDCFP0000V2
HDCGP0000V2
18× Color (HDXA)
18× WDR/TDN (HDXJ)
26× WDR/TDN (HDXF)
35× WDR/FNR (HDXG)
Table A-3 Housing Specifications
Specification In-ceiling
Housing
Indoor Pendant
Housing
Outdoor Pendant
Housing
Rugged
Table A-5 Camera Specifications
18× Color 18× WDR/TDN 26× WDR/TDN 35× WDR/FNR/EIS
Image sensor 1/4-type EXview HAD
CCD™
1/4-type EXview HAD
CCD™
1/4-type EX-view HAD
CCD™
1/4-type Progressive
Scan CCD
Lens 18× optical zoom,
F=4.1 mm (wide) to
73.8 mm (tele), F1.4 to
F3.0
18× optical zoom,
F=4.1 mm (wide) to
73.8 mm (tele), F1.4 to
F3.0
26× optical zoom,
F=3.5 (wide) to 91
mm (tele), F1.6 to F3.8
35× optical zoom,
F=3.4 (wide) to 119
mm (tele), F1.4 to F4.2
Horizontal
resolution
470 TVL (NTSC)
460 TVL (PAL)
530 TVL (NTSC)
530 TVL (PAL)
530 TVL (NTSC)
530 TVL (PAL)
> 520 TVL (540
typical)
True Day/Night No Yes Yes Yes
Wide Dynamic
Range (WDR)
No 128× 128× 128×
