Configuring Video
Setting the Video Resolution
ACUIX™ IP video is available in three resolutions: CIF, 2CIF, and 4CIF. CIF is the
lowest resolution and 4CIF is the highest (see Table 10-1). By default, the video
resolution is set to 4CIF.
To set the video resolution:
1. Click the Compression Settings tab.
2. In the Compression Settings panel, in the Resolution box, select one of
the following:
• 4CIF (default)
•2CIF
•CIF
3. Click Apply.
Setting the Frame Rate
To set the frame rate:
1. Click the Compression Settings tab.
2. In the Compression Settings panel, in the Frame Rate box, select a value
from 1 to 30 (NTSC, default = 30) or from 1 to 25 (PAL, default = 25).
3. Click Apply.
Setting the Priority
You can set either Quality or Bit Rate as the priority.
If Quality is selected, when the target bit rate exceeds the maximum bit rate
value, the camera prioritizes picture quality over adjusting the frames to maintain
the bit rate below the maximum bit rate value.
If Bit Rate is selected, when the target bit rate exceeds the maximum bit rate
value, the camera prioritizes adjusting the frames to maintain the bit rate below
the maximum bit rate value.
Table 10-1 Video Resolution
Format NTSC Resolution PAL Resolution
CIF 352 × 240 pixels 352 × 288 pixels
2CIF 704 × 240 pixels 704 × 288 pixels
4CIF 704 × 480 pixels 704 × 576 pixels
