EQUIP
®
Series ACUIX™ IP PTZ Dome Installation and Configuration Guide
Document 800-04194V1 Rev A 113
07/11
Mount Specifications
Housing Specifications
Table A-2 Mount Specifications
Specification Ceiling Mount
HDCM1
Parapet Mount
HDPRM2
Wall Mount
HDXWM2
Construction Aluminum Aluminum, steel,
and stainless
hardware
High tensile
aluminum alloy
Finish Warm Gray Warm Gray Warm Gray
Environment Indoor Indoor and outdoor Indoor and outdoor
Maximum Load 25 lb. (11.34 kg) 20.1 lb. (9.1 kg) 25.8 lb. (11.7 kg)
Unit Weigh: 4 lb. (1.8 kg) 22.5 lb. (10.2 kg) 3.2 lb. (1.45 kg)
Table A-3 Housing Specifications
Specification In-ceiling
Housing
Indoor Pendant
Housing
Outdoor Pendant
Housing
Rugged
Housing Height 6.7 in. (170.21 mm) 7.5 in. (190.5 mm) 7.5 in. (190.5 mm) 6.95 in. (176.5 mm)
Housing Diameter
8.13 in. (206.45 mm)
9.25 in. (235 mm) 10.0 in. (254 mm) 10.52 in. (267.2 mm)
Housing Flange
Diameter
8.0 in. (203.2 mm) 9.25 in. (235 mm) 9.25 in. (235 mm) 8.0 in. (203.2 mm)
Housing Material Aluminum Aluminum Aluminum Aluminum
Lower Dome
Diameter
6.60 in. (168 mm) 7.5 in. (191 mm) 7.5 in. (191 mm) 7.5 in. (191 mm)
Lower Dome
Material
Acrylic Acrylic Acrylic Acrylic
Mounting Method Three retractable
tabs recessed into
the housing flange
1.5 in. NPT 1.5 in. NPT Mounting bracket
IP Rating — — IP66 IP66
NEMA Rating —- — NEMA 4× NEMA 4×
Operating Voltage 24 V AC ± 10% 24 V AC ± 10% 24 V AC ± 10% 24 V AC ± 10%
Operating Current 2.0 A 2.0 A 2.6 A 2.6 A
