Installing the Housing
This chapter contains the following sections:
• About ACUIX™ IP Housings, page 3
• Cable Preparation, page 4
• Installing Mounts and Adapters, page 5
• Installing an In-Ceiling Housing, page 9
• Installing a Pendant Housing, page 12
• Installing a Rugged Housing, page 13
• Connecting the Field Wiring, page 15
About ACUIX™ IP Housings
ACUIX IP housings are available in three styles: in-ceiling (indoor), pendant
(indoor/outdoor), and rugged (outdoor):
Figure 2-1 Housing Styles
Each housing contains an interface board for connecting power, network, and
alarm wiring. Outdoor housings also include a heater and a fan blower. A variety
of mounts and adapters are available for use with pendant and rugged housings
(see Installing Mounts and Adapters on page 5).
