EQUIP
®
Series ACUIX™ IP PTZ Dome Installation and Configuration Guide
Document 800-04194V1 Rev A 57
07/11
Setting the Vertical Phase Edge
Vertical Phase Edge, or line lock, lets you synchronize all analog cameras
connected to the same power line. This prevents the picture on the screen from
rolling vertically when switching from one camera to another.
Line lock can also help an analog VCR to remain in sync when switching
between properly adjusted, line-locked cameras. Line lock is generally of no
benefit with digital (LCD or flat screen) monitors and DVRs.
Note You need an AC power supply to use this feature.
To enable/disable vertical phase edge:
1. From the OSD main menu, press 5 to select Camera Options.
2. Press 6 to set Vert Phase Edge to ON or OFF (default).
To set the vertical phase edge:
1. From the OSD main menu, press 5 to select Camera Options.
2. Press 6 to set Vert Phase Edge to ON.
3. Press 7 to select Vert Phase 0–359.9.
4. Type a value from 0 (default) through 359.9 and then press ENTER.
The value expresses, in degrees, the adjustment required overcome the
difference between connected AC supply phases.
Setting Wide Dynamic Range
This feature is only available with HDXJ and HDXF cameras. It is not available with
HDXA cameras.
Wide dynamic range technology provides clear, balanced images in a variety of
lighting conditions, such as entrances with varying levels of indoor/outdoor
illumination and situations where backlighting makes it difficult to see a
foreground subject clearly. Wide dynamic range improves detail in
underexposed (dark) and overexposed (light) areas but can lead to unnatural
looking video.
