Document 800-04194V1 Rev A 37
07/11
5
Configuring the OSD Menu
This chapter contains the following sections:
• Opening the OSD Main Menu, page 37
• Changing the OSD Menu Language, page 38
• Displaying the Dome Address, page 38
• Displaying Sectors and Presets, page 39
• Displaying the Zoom Magnification, page 39
• Displaying the Startup Screen, page 40
• Displaying Crosshairs, page 40
• Displaying the Dome Name, page 40
• Displaying Pan, Tilt, and Zoom Information, page 41
• Displaying the Time and Date, page 41
Opening the OSD Main Menu
The on-screen display (OSD) main menu is used to set up the dome. From this
menu you can configure dome control, camera settings, diagnostic settings, and
programming settings.
To open the OSD main menu:
1. Open the ACUIX IP web client application in your browser and log on as an
administrator (see
Logging On to the ACUIX™ IP Web Client Application
on
page
28
).
2. Click the PTZ Dome Setup tab.
3. In the Camera Menu panel, click Open Camera Menu.
The OSD main menu appears on the screen. To exit the menu, press ESC.
