Configuring HDXA, HDXJ, and HDXF Camera Settings
To set the red gain:
1. From the OSD main menu, press 5 to select Camera Options.
2. Press 4 to select White Balance.
3. Press 5 to set manual white balance to ON.
4. Press 6 to select Red Gain 0-255.
5. Type a value from 0 through 255 (default = 200) and then press ENTER.
To set the blue gain:
1. From the OSD main menu, press 5 to select Camera Options.
2. Press 4 to select White Balance.
3. Press 5 to set manual white balance to ON.
4. Press 7 to select Blue Gain 0-255.
5. Type a value from 0 through 255 (default = 200) and then press ENTER.
Setting E-Flip and Mirror Image
This feature is only available with HDXJ and HDXF cameras. It is not available with
HDXA cameras.
E-Flip turns the image upside down. Mirror Image reverses the image
horizontally.
To enable/disable E-Flip:
1. From the OSD main menu, press 5 to select Camera Options.
2. Press 5 to select Video Options.
3. Press 2 to set E-Flip to ON or OFF (default).
To enable/disable Mirror Image:
1. From the OSD main menu, press 5 to select Camera Options.
2. Press 5 to select Video Options.
3. Press 3 to set Mirror Image to ON or OFF (default).
