EQUIP
®
Series ACUIX™ IP PTZ Dome Installation and Configuration Guide
Document 800-04194V1 Rev A 17
07/11
Setting the Protocol (SW5)
The ACUIX IP PTZ dome supports the following protocols for communicating
with other devices:
• IntelliBus™ (recommended)
•MAXPRO-mode (default)
•VCL
• Diamond
•Pelco P
•Pelco D
The protocol is set using DIP switch SW5 on the main board (see Table 3-2). The
factory default is MAXPRO-mode (a mode of using Diamond protocol that has
special presets for functions beyond pan, tilt, zoom, focus, and preset).
Select a protocol that is compatible with the device that you want to connect to.
IntelliBus™ protocol is recommended for most installations.
To set the protocol:
1. Remove the scan assembly from the pink antistatic bag.
2. Using Table 3-2 as a reference, position the pins on switch SW5 to
correspond to the protocol that you have selected.
Note Normally, pin 8 should be set to the ON position. Setting the switch to
OFF allows the address, protocol, baud rate, and parity settings to be
changed from the OSD, which is not recommended for most
installations.
Table 3-2 SW5 Protocol Settings
Protocol Name Switch Position
12345678
IntelliBus™ OFF OFF OFF OFF OFF OFF OFF ON
MAXPRO-mode
(default)
OFF ON OFF OFF OFF OFF OFF ON
VCL - RS485
ON ON OFF OFF OFF OFF OFF ON
Diamond ON OFF OFF OFF OFF OFF OFF ON
Pelco P ON OFF ON OFF OFF OFF OFF ON
Pelco D OFF ON ON OFF OFF OFF OFF ON
