HP 9000 rp3410 - Figure 6-16 Fan 1 A or Fan 1 B Removal; Figure 6-17 Fan 2 Removal

Chapter 6
Removing and Replacing Components
Removing and Replacing System Fans
162
a. To remove fan 1A, 1B, 2 or 3 from a rack-mounted server, or fan 3 from a pedestal server, grasp
the appropriate fan and lift it out of the fan socket (Figure 6-16; Figure 6-17; Figure 6-18).
Figure 6-16 Fan 1A or Fan 1B Removal
Figure 6-17 Fan 2 Removal
Fan 1A
Fan 1B
Fan 2
