No. Port Silk
Screen
Port Name
8 Reserved N/A
Figure 3-50 shows routes of the outdoor unit
on/o signal cable and water sensor
signal cable.
● The female connector needs to be removed from the wiring terminal on the
external signal port. After the cable is connected to the female connector,
reconnect the connector to the wiring terminal.
● Avoid reverse connection for X301 and X302 terminals.
Figure 3-50 Routes of the outdoor unit on/o signal cable (dry contact) and
water sensor signal cable
NetCol5000-A025 In-row Air Cooled Smart Cooling
Product
User Manual (300 mm Width) 3 Installation Guide
Issue 15 (2020-12-10) Copyright © Huawei Technologies Co., Ltd. 81
