12-38
12. GPS OPERATION (ADVANCED)
GPS SET
Speed (Default: 0mph)
Sets the Item’s speed to between 0 and
1150 mph.*
* If the Speed unit is set to “km/h,” set to between 0 to
1850 km/h, or set to “knots,” set to between 0 and
999 knots.
LThis item is displayed when “Data Extension” is set
to “Course/Speed.”
Power (Default: 0W)
Selects the TX power level of Item, to transmit
along with the position data.
LThis item is displayed when “Data Extension” is set
to “Power/Height/Gain/Directivity.”
• Select 0, 1, 4, 9, 16, 25, 36, 49, 64, or 81 W.
Height (Default: 10ft)
Selects the height of the Item’s antenna, to
transmit along with the position data.
LThis item is displayed when “Data Extension” is set
to “Power/Height/Gain/Directivity.”
• Select 10, 20, 40, 80, 160, 320, 640, 1280,
2560, or 5120 feet.*
* If the Altitude/Distance unit is set to “m,” select 3, 6,
12, 24, 49, 98, 195, 390, 780, or 1561 meters.
Gain (Default: 0dB)
Selects the gain of the Item’s antenna, to transmit
along with the position data.
LThis item is displayed when “Data Extension” is set
to “Power/Height/Gain/Directivity.”
• Select between 0 and 9 dB.
Directivity (Default: Omni)
Selects the direction the Item’s antenna was
pointing, to transmit along with the position data.
LThis item is displayed when “Data Extension” is set
to “Power/Height/Gain/Directivity.”
• Select Omni, 45º NE, 90º E, 135º SE, 180ºS,
225º SW, 270º W, 315º NW, or 360º N.
SSID (Default: ---)
Selects an SSID based on APRS
®
to add to
your call sign, to show your operating style to
other stations. The additional methods of the
SSID differ, depending on whether the call sign
includes a space or not.
LSee page 12-33 for details of the SSID.
• ---: The space in call sign is converted to
“-.”
• (-0): No SSID is added.
• -1 ~ -15: Adds an SSID of -1 to -15 to your call
sign.
• -A ~ -Z: Adds an SSID of -A to -Z to your call
sign.
