Icom IC-705 - BK Mode Communication

14-14
14. D-STAR OPERATION (ADVANCED)
1. While 2 stations are communicating in the DV
mode, touch
for 1 second.
• After releasing , the calling station’s call
sign or the repeater’s call sign is set to “TO”
(Destination).
• Beeps sound, and the calling station’s call sign
is announced.
LWhen a call sign is not received correctly, error
beeps sound, and no call sign is set.
2. Open the BK screen.
»
SET > DV SET > BK
3. Touch “ON.”
4. To close the DV SET screen, push
several times.
• Returns to the standby screen, and “BK” is
displayed.
5. When both stations are in standby, hold down
[PTT] to transmit.
L“BK” blinks when receiving a Break-in call.
LTo cancel the BK mode, touch “OFF” in step 3,
or turn OFF the transceiver.
How to use Break-in?
While using the Digital Call Sign squelch (DSQL), the squelch never opens (no audio is heard) even if a
call is received, unless the call is addressed to your own call sign.
However, when a call including the “BK ON” signal (break-in call) is received, the squelch opens and
audio is heard even if the call is addressed to another station.
Station C calling to Station A with “BK OFF” Station C calling to Station A with “BK ON”
BK mode communication
The Break-in (BK) function enables you to break into a conversation, where the 2 stations are
communicating with call sign squelch (DSQL) enabled.
LThe BK function is automatically turned OFF when you turn OFF the transceiver.
LThis function can be used in the DV mode.
Station A
Station B
Station C
Station A
Station B
Station C
Station A
and B are
communicating
using the
Digital Call Sign
squelch.
Station B does not hear that
Station C is calling Station A.
Station B also hears that
Station C is calling Station A.
Station A
and B are
communicating
using the
Digital Call Sign
squelch.
