15-14
15. ABOUT THE DV GATEWAY FUNCTION
Terminal mode operation
DSetting the Terminal mode
1. Open the DV GATEWAY screen.
»
2 > DV GW
2. Touch “<<Terminal Mode>>.”
Internal Gateway icon
“Ext” is displayed when using the
External Gateway function.
When using the External Gateway function
After the transceiver is in the Terminal mode,
click (touch) <Start>
in the RS-MS3W or
RS-MS3A.
LIf an error message is displayed, see page 15-26 for
tips on how to solve the problem.
NOTE: In the Terminal mode
• The Power Save function and the Time Out Timer
function are not activated.
• The following items are automatically set.
Operating mode: DV mode*
DR function: ON*
FROM: MY Call Sign
RIT function: OFF
P.AMP function: OFF
ATT function: OFF
* These settings do not return to the previous
settings, even if you cancel the Terminal mode.
• The Terminal mode is not automatically canceled,
even if you turn OFF the transceiver, then turn it
ON again.
TIP: Canceling the Terminal mode
Touch “<<Normal Mode>>” in the DV
GATEWAY screen.
»
2 > DV GW > <<Normal Mode>>
LWhen using the External Gateway function, click
(touch) <Stop>
in the RS-MS3W or RS-MS3A
before the transceiver returns to the normal mode.
About the Internal Gateway icon
When using the Internal Gateway function,
displays the communication status.
Icon Status
In the standby mode
While transmitting
While receiving
Transmission error (The repeater is busy.)
Transmission error
Network error
Receiving while transmitting
Receive error
LIf an error icon is displayed, see page 15-21 to
read the tips to solve the problem.
To Next Page
