12. GPS OPERATION (ADVANCED)
Transmitting D-PRS data
DAbout the weather data content
The weather data should be input according to
the format (based on the APRS
®
Weather Data),
shown below.
Example:
220/004 g005 t077 r000 p000 P000 h50 b09900 End code
1 2 3 4 5 6 7 8 9
No� Item Value Unit
1 Wind direction 000 to 360 º
2 Wind speed 000 to 999 mph
3 Gust speed g000 to g999 mph
4
Temperature t-99 to t-01,
t000 to t999
ºF
5 Rainfall r000 to r999*
1
inch
6 Rainfall (24 Hours) p000 to p999*
1
inch
7 Rainfall (Midnight) P000 to P999*
1
inch
8
Humidity h00, h01 to h99
(h00 indicates 100%.)
%
9
Barometric pressure b00000 to b99999*
2
hPa,
mb
*
1
The last two digits indicate the one decimal place and the
two decimal place.
*
2
The last digit indicates the one decimal place.
LIf you have no data, enter a space or “.” (period)
instead of a number.
(Example: “.../...g...t077r000p...P...h50b.....”)
LEnter <CR>, <LF>, or <CR><LF> for an end code.
