10-3
10.
Bluetooth
®
OPERATION
Bluetooth
®
Settings
DAF Output
You can select the AF Output device.
If “AF Output” is set to “Headset & Speaker,” you
can hear audio from both a connected Bluetooth
headset and the transceiver’s speaker.
1. Open the HEADSET SET screen.
»
SET > Bluetooth Set > Headset Set
2. Touch “AF Output.”
3. Touch “Headset & Speaker.”
4. To close the HEADSET SET screen, push
several times.
LAudio is heard from both the connected
Bluetooth headset and the transceiver’s
speaker.
DHeadset Function Select
You can select the PTT and microphone
combination when either a Bluetooth headset or
the transceiver microphone are used.
1. Open the HEADSET SET screen.
»
SET > Bluetooth Set > Headset Set
2. Touch “Headset Function Select.”
3. Touch an option.
4. To close the HEADSET SET screen, push
several times.
NOTE: DO NOT select “PTT” when you use
only the Bluetooth headset.
Select “Microphone”
Using the Bluetooth headset
as a microphone.
Select “PTT”
Using the Bluetooth headset
as a PTT switch.
Push PTT on the
microphone
Push PTT on the
microphone
Voice from the
microphone
Voice from the
microphone
Push PTT on the
Bluetooth headset
Voice from
the Bluetooth
headset
TIP: When “AF Output” is set to “Headset Only,”
the following dialog is displayed if the Bluetooth
connection is accidentally disconnected.
• [YES]: The audio is output from the transceiver’s
speaker.
• [NO]: The transceiver’s volume level is
automatically set to 0%, and the audio is
not output from the transceiver’s speaker.
To Next Page
