Icom IC-705 Advanced Manual

13-14
13. D-STAR OPERATION (BASIC)
About Reflectors
DRequesting repeater information
When you send the repeater information
command, an ID message is sent back.
1. Touch “TO” to select, and then touch “TO”
again.
2. Touch “Reflector.”
3. Touch “Repeater Information.”
• Returns to the DR screen, and “Repeater
Information” and “I” are displayed in “TO.”
4. Hold down [PTT] to transmit the repeater
Information command.
5. Release [PTT] to hear the repeater ID
message.

Icom IC-705 Specifications

General

Bluetooth	Yes
WLAN	Yes
SD Card Slot	Yes
Antenna Connector	BNC
Frequency Range	0.030–199.999 MHz
Modes	SSB, CW, AM, FM
Receiver Type	Superheterodyne
GPS	Built-in
Battery	Lithium-ion
Weight	Approx. 1.1 kg
Type	Portable
Power Supply	13.8 V DC
Waterproof Standard	IP54
Operating Temperature Range	-10°C to +60°C
Display	4.3 inch color TFT touch screen LCD
